Description
Designed for NZÂ
A Great Entry-Level Outdoor Track Blind System
Atlas Blinds are a premium windproof roller blind system featuring a fully enclosed cassette, zip-guided side rails, and a stabilised bottom beam. Built with high-grade aluminium components and reinforced internal fittings, they are ideal for pergolas, patios, commercial hospitality, and exposed outdoor living areas.
For New Zealand’s high-wind locations, we recommend choosing Titan Blinds for the highest performance and wind resistance.
System Overview
Atlas Blinds use a zipper slide system inside aluminium side rails, keeping the fabric secure in windy conditions. The enclosed headbox ensures long-term durability and protects the fabric from weather exposure.
Cassette Options
Class 125 System
• 125mm x 125mm
• Heavy-duty for larger widths
• Ideal for motorised blinds
Class 100 System
• 100mm x 100mm
• Compact option
• Ideal for manual blinds
Maximum Sizes
Motorised Atlas Blinds
Maximum Width: 6m
Maximum Height: 3m
Manual Atlas Blinds
Maximum Width: 4m
Maximum Height: 3m
Colour Options
• Sand Grey
• White
• Coffee (Brown)
Custom Colour with surcharge
Components & Materials
Aluminium Parts
Upper & Lower Cover Shell
Side Rail Assembly
Lower Beam
Reelpipe
End Plate
End Disk Plug
Injection-Moulded & Steel Parts
Tail Plug (Nylon + stainless steel)
Runner / Wheel (Nylon injection)
Motor Bracket (Galvanised steel)
Spring Wire (Stainless steel)
Side Rail Sealing (PVC + Nylon)
Lower Beam Sealing (Nylon injection)
Zipper Slide
Engineered for long-term reliability in outdoor conditions.
How Atlas Blinds Work
Fabric rolls neatly inside a fully enclosed cassette
Zipper track keeps fabric locked inside the side rails
Lower beam seals against wind and insects
Manual or motorised operation options
All mechanisms protected from weather and UV
Why Choose Atlas Blinds?
✔ Windproof zip-slide system
✔ Suitable for pergolas, patios & commercial spaces
✔ Motorised up to 6m, manual up to 4m
✔ Maximum height: 3m
✔ Clean, modern, fully enclosed design
✔ Built for NZ’s tough outdoor environments
✔ Titan Blinds recommended for high-wind regions
