Description
Inspired, Effortless Shade
The Shadowspec Retreat™ is the ultimate wall-mounted umbrella designed for modern outdoor living. Perfect for patios, decks, cafés, and balconies, this compact yet powerful system provides reliable shade and weather protection without taking up valuable floor space.
Built from anodised aluminium and 316 stainless steel, the Shadowspec Retreat combines strength, durability, and sleek design. Every element is crafted to ensure long-term performance in coastal and urban environments, making it ideal for both residential and commercial settings.
Key Features
Follow the Sun with Dynamic Shade Control
-
Rotates – Enjoy shade throughout the day with smooth 180° rotation.
-
Tilts – Two adjustable tilt positions provide protection when the sun is low.
-
Extends – Reach full coverage with the extendable arm design.
Patented Shadowspec Technology
-
SHADOWLIFT™ – Gas-assisted deployment allows effortless opening and closing.
-
SHADOWREACH™ – Extendable reach system for maximum coverage.
-
SHADOWROLL™ – Integrated roller ensures smooth, controlled movement.
-
SHADOWTILT™ – Keeps you shaded from low-angle sunlight.
Each mechanism works seamlessly to deliver hands-free, effortless operation with precise control and minimal maintenance.
Premium Materials & Design
The Shadowspec Retreat™ uses only marine-grade materials to ensure longevity:
-
Frame: Anodised Aluminium and 316 Stainless Steel for corrosion resistance.
-
Canopy: Solution-dyed, fade-resistant fabric with UPF 80 UV protection.
-
Eco-Friendly: Manufactured using sustainable, low-impact production methods.
Fabric & Colour Options
Choose from five designer colours that complement contemporary architecture:
-
Oyster
-
Alpine Stone
-
Charcoal Tweed
-
Rust
-
Black & White Stripe
The canopy material is UV and fade resistant, water resistant, and mould and mildew proof. It also features:
-
High Colour Fastness
-
Oil and Stain Repellence
-
Tear Resistance
-
Easy-Clean Surface
-
Chlorine Resistance
These characteristics ensure your umbrella looks great and performs perfectly for years to come.
Technical Specifications
| Parameter | Metric (mm) | Imperial (ft/in) | Description |
|---|---|---|---|
| A | 295 | 1’ | Canopy height when deployed |
| B | 526 | 1’9’’ | Wall bracket length |
| C | 441 | 1’4’’ | Space from wall bracket to wall clip |
| D | 1209 | 4’ | Recommended gap from wall clip to ground |
| E | 1419–1875 | 4’8’’–6’2’’ | Wall to centre hub distance |
| F | 2609–3065 | 8’7’’–10’0’’ | Wall to outer canopy edge |
| G | 2014 | 6’7’’ | Ground to centre hub distance |
| H | 2166 | 7’1’’ | Ground to canopy edge |
| I | 300 | 1’ | Closed umbrella depth |
| J | 95 | 4’’ | Wall bracket width |
| K | 130–150 | 5–6’’ | Closed umbrella width |
| L | 2300 | 7’7’’ | Canopy flat-to-flat |
| M | 2700 | 8’10’’ | Canopy point-to-point (full extension) |
Note: All dimensions are ±2.5 mm. Measurements are based on the recommended installation height. For commercial installations, metric dimensions are recommended for accuracy.
Shadowspec-Brochure-RETREAT-AN-…
Warranty
-
Frame Warranty: 8 Years
-
Fabric Warranty: 3 Years
(1-year commercial warranty applies to heavy-use environments.)
Why Choose the Shadowspec Retreat™?
-
Space-saving wall-mounted design ideal for compact areas
-
Marine-grade materials built to withstand coastal conditions
-
Gas-assisted lift and precision-engineered motion
-
Sleek architectural style with designer colour options
-
Low-maintenance and eco-friendly fabric technology
-
Excellent UV protection (UPF 80) and all-weather performance
