Description
Heavy-Duty Shade for Commercial & Residential Spaces
If you need a serious shade solution for cafés, resorts, hospitality venues, or large home patios, the SU10 Commercial Centre Pole Umbrella is engineered for high-demand environments. With a reinforced aluminium frame, marine-grade canopy fabric, and multiple mounting choices, it’s built to perform year after year with minimal maintenance.
Why the SU10 is a Top Choice
• Engineered for Commercial Use
Built with a commercial-grade aluminium frame and heavy-duty strut arms, the SU10 is ideal for cafés, restaurants, hotels, and public spaces where durability is essential.
• Proven Performance in NZ Conditions
Stainless steel hardware and weather-resistant fittings ensure the umbrella stands up to New Zealand’s coastal, alpine, and high-wind environments.
• Telescopic Mast for Easy Operation
The telescopic system allows the umbrella to close above standard outdoor furniture, meaning tables and chairs don’t need to be moved when closing it down.
• Long-Term Warranty Support
Backed by strong warranty coverage, providing confidence and reliability for long-term installations.
Premium Marine-Grade Canopy Fabric
The SU10 canopy is manufactured for extreme outdoor performance:
Marine solution-dyed fabric
Waterproof rating: 300+ mm water column
Fabric weight: 315 g/m²
Colourfastness: 7–8/8 (excellent resistance to fading)
UV Protection: UPF 80
Low Maintenance: Easy to wash and replace as needed
A wide range of colours is available, including charcoal tweed, ocean blue, oyster white, sunflower yellow, and other designer tones. Special-order colours can be arranged for premium projects.
Heavy-Duty Frame Construction
The frame is engineered for strength, stability, and commercial performance:
82.5 mm diameter mast with 3.4 mm wall thickness
50 × 25 mm heavy-duty strut arms
Reinforced hubs and connection points
Stainless steel hardware for long-term durability
This makes the SU10 suitable for exposed coastal environments, hospitality settings, and high-use areas.
Sizes & Configurations
Available in large commercial sizes designed to maximise coverage:
4.0 m square
5.0 m square
Key dimensions include:
Canopy widths of 4000 mm or 5000 mm
Overall heights between 2870 mm – 3120 mm when open
Smart mast design maintaining comfortable clearance levels
Heights may vary based on the selected mounting method.
Mounting Options
Choose the base style that fits your installation:
• Surface Plate
Bolts directly to concrete patios, decks, and slab areas.
• In-Ground Anchor
Ideal for permanent installations requiring maximum stability.
• Free-Standing Base (Optional Castor Wheels)
Perfect for flexible layouts, allowing quick repositioning as needed.
Concrete pavers required for ballast.
Available Accessories
• Rain Gutter System
Join two umbrellas together to create a larger weather-protected area — ideal for commercial terraces, outdoor dining, and events.
• Castor Wheels for Free-Standing Base
Make it easy to move the umbrella around your space.
Ideal For
Cafés and hospitality venues
Restaurants and bar terraces
Resort and hotel pool areas
Commercial courtyards
Large residential patios
Outdoor event spaces
