Description
Enhance your outdoor space with the Terrafold Full Cassette Awning range. Designed for strength, style, and seamless operation, the LCF and LCC models deliver robust protection from sun and rain while adding elegance to your patio, balcony, or commercial façade.
These full cassette awnings are built with premium materials and engineering precision, making them suitable for residential homes, cafés, storefronts, and outdoor entertainment areas.
✅ Key Specifications (Both LCF & LCC Models)
Cassette Size: 149 × 177 × 2.8 mm (Aluminium)
Roller: Steel Φ78 × 1.0 mm (for widths up to 4.5 m)
Steel Φ80 × 1.2 mm (for widths above 4.5 m)Front Beam: 120 × 64.8 × 2.8 mm (Aluminium)
Arm Sizes:
Big Arm – 61 × 33 × 3.0 mm
Small Arm – 52 × 28 × 2.5 mmWarranty:
5 Years standard warranty
10 Years no-fade warranty for Dickson acrylic fabric
🎨 Available Fabric & Control Options
Remote + Manual (No LED Light)
Polyester
Chinese Acrylic
Dickson Acrylic
Remote + Manual with Adjustable LED Light
Polyester
Chinese Acrylic
Dickson Acrylic
📏 LCF Model – Available Sizes (Width × Projection)
| Width (m) | Projection (m) |
|---|---|
| 2.5 | 1.5 |
| 3.0 | 1.5, 2.0 |
| 3.5 | 1.5, 2.0, 2.5 |
| 4.0 | 1.5, 2.0, 2.5, 3.0 |
| 4.5 | 1.5, 2.0, 2.5, 3.0 |
| 5.0 | 1.5, 2.0, 2.5, 3.0 |
📏 LCC Model – Available Sizes (Width × Projection)
| Width (m) | Projection (m) |
|---|---|
| 5.5 | 1.5, 2.0, 2.5, 3.0, 3.5, 4.0 |
| 6.0 | 1.5, 2.0, 2.5, 3.0, 3.5, 4.0 |
| 6.5 | 1.5, 2.0, 2.5, 3.0, 3.5 |
| 7.0 | 1.5, 2.0, 2.5, 3.0, 3.5, 4.0 |
