In the realm of outdoor architecture, the transition from simple shade structures to fully engineered living environments represents a significant shift in property value and lifestyle utility. The Cerberus Plus System is positioned as a high-performance mid-range kitset, bridging the gap between cheap imports and expensive custom builds. This guide details the technical specifications, operational nuances, and modular possibilities of an accessible, structural-grade system designed to withstand the rigours of the Pacific climate while delivering a clean architectural finish.
The foundation of any permanent outdoor structure is the material grade. The Cerberus Plus utilizes 6063-T5 structural-grade aluminium. This specific alloy is chosen for its superior strength-to-weight ratio and excellent corrosion resistance, making it the industry standard for architectural extrusions.
Unlike standard residential-grade aluminium, the T5 tempering process involves air cooling and artificial aging, which increases the hardness and structural integrity of the profiles. This ensures that the louvre blades and framing members maintain their shape under high thermal stress and physical load. Complementing this structural frame are 304 stainless steel fixings. Stainless steel is non-negotiable in coastal or high-moisture environments; it prevents the galvanic corrosion and "tea-staining" that often plagues systems using inferior zinc-plated or galvanized fasteners.
For homeowners and developers in wind-prone regions, the most critical metric is the wind load rating. The Cerberus Plus is engineered to withstand wind speeds up to 150 km/h. Achieving this rating requires precision in the interlocking mechanism of the louvres and the gauge of the support columns.
When fully closed, the louvres form a structural "skin" that distributes wind pressure across the entire frame. This level of engineering provides peace of mind during seasonal storms, ensuring the structure remains a permanent fixture rather than a temporary shelter.
Choosing between a manual and a motorised configuration depends on the intended frequency of use and the desired level of automation. Both options provide 135-degree rotation for the louvres, allowing for precise control over light, heat, and airflow.
The manual version utilizes a high-torque internal gearbox and a removable hand crank. This system is ideal for remote locations or installations where electrical wiring is not feasible. The mechanical advantage of the gearbox ensures that even large-scale louvre banks can be operated with minimal physical effort.
The motorised Cerberus Plus Louvre Kitset System brings the outdoor room into the digital age. Key features include:
A standout feature of the Cerberus Plus is its adaptability to existing architecture. While the system is available as a complete, freestanding kitset with 120mm x 120mm support columns, it is also highly effective as a "roof-only" retrofit.
Many properties have existing timber or steel pergolas that are structurally sound but lack effective weather protection. The Cerberus Plus roof system can be integrated into these existing frames, providing a modern louvre solution without the cost of a full demolition and rebuild. This is particularly useful for matching the aesthetic of a traditional home while upgrading its functionality. For those looking at broader renovations, exploring the Shop reveals various components that can complement these hybrid structures.
One of the most complex challenges in outdoor kitchen design is managing heat and smoke. Standard louvre systems often prohibit the use of wood-fired ovens because the heat can damage the aluminium or the smoke can become trapped under the roof.
The Cerberus Plus solves this with a specialized chimney solution. This involves a custom-engineered panel that allows a flue from an appliance, such as the Vulcan Fire Grill, to pass safely through the louvre roof.
A high-performance mid-range louvre system is only as good as its drainage. The Cerberus Plus features an internal guttering system. When the louvres are closed, they overlap to form a watertight seal. Rainwater is directed into integrated channels within the louvre blades, which then flow into the perimeter beams.
From the beams, the water is channeled internally down through the support columns, exiting at the base. This invisible drainage keeps the perimeter of the structure clear of dripping water, maintaining the clean architectural lines of the system.
The Cerberus Plus is designed to be the "shell" of an outdoor room. As needs change, the system can be upgraded with modular add-ons to create a fully enclosed sanctuary.
Visual harmony is achieved through a selection of architectural finishes. The system is available in several powder-coated finishes that are UV-stable and resistant to fading:
These finishes are applied to a high micron thickness, ensuring the system requires only minimal maintenance: typically a simple wash-down with fresh water: to maintain its appearance for years.
The Cerberus Plus System represents a durable, smart mid-range kitset solution, prioritizing structural integrity and practical functionality.
By focusing on these technical and design fundamentals, property owners can ensure they are investing in a system that delivers accessible structural performance, smart usability, and long-term durability without stepping into full custom-build territory.
